Description
● The drum chipper is the special equipment for producing perfect chips, and it is used in paper plants, particle board plants, fiber-broad plants, chip production and export bases. By which, logs and small wood are cut into high quality with even length and uniform chip thickness. It is also suitable for the chipping of branches and twigs, and planks.
● The chip length is different in accordance with the requirements of paper plants, particular broad and fiber-board industries. In order to meet this need, our company has improved different kinds of drum chippers recently, and the new type machines have more advantages. All the features show that it is an ideal equipment for chip production.
Technical Parameter
Model |
BX216 |
BX218 |
BX218D |
BX2110 |
BX2113 |
Rotor diameter (mm) |
650 |
800 |
800 |
1000 |
1300 |
Number of fly-cutter (piece) |
3 |
3 |
3 |
3×2 |
3 |
Feeding inlet (mm) |
280×500 |
330×770 |
330×770 |
400×1050 |
450×700 |
Rotating speed (rpm) |
590 |
650 |
650 |
550 |
420 |
Feeding speed (m/min) |
37 |
37 |
38 |
38 |
35 |
Feeding max diameter (mm) |
150 |
250 |
250 |
330 |
400 |
Chip length (mm) |
20-30 |
22-30 |
22-30 |
25-35 |
25-35 |
Capacity (t/h) |
4-6 |
5-8 |
7-11 |
22-30 |
22-30 |
Main power (KW) |
55 |
110 |
132 |
220 |
200-250 |
Feeding motor power (KW) |
3×2 |
4×2 |
4×2 |
7.5×2 |
7.5×2 |
Weight (t) |
4.5 |
7 |
7.5 |
11.5 |
13 |
Overall size (mm) |
4348×1730×1250 |
4670×2150×1500 |
2200×2150×1500 |
4340×3550×1500 |
3670×2517×2050 |
